– 15 –

CONTENTS

WARRANTY AND PRODUCT REGISTRATION 4

OMPLIANCES AND SAFETY STATEMENTS 5

BOUT THIS GUIDE 13

ONTENTS 15

NTRODUCTION 17

Overview 17

Features 17

PoE Features 18

2HARDWARE DESCRIPTION 19

Front Panel 19

Port and System Status LEDs 19

RJ-45 Ports 20

Rear Panel 20

AC Power Socket 20

3INSTALLING THE SWITCH 21

Package Contents 21

Precautions 21

Safety Requirements 21

Location Requirements 22

Installation 22

Desktop Installation 23

Rack Installation 23

Connecting to Ground 25

Powering On 26
