4 PRODUCT APPLICATIONS
DEPARTMENT/WORKGROUP POE SWITCH
The SMCFS801P provides 8 PoE port interfaces and can build a centrally-
controlled IP phone system, IP camera system, or wireless AP group for the
enterprise. Cameras can be installed around the company or campus for
surveillance needs, or wireless APs can build a wireless roaming environment in
the office. Without being limited by power-socket availability, the switch makes
installation of cameras or wireless APs easy and efficient.
Figure 7: Applications
Centre of Surveillance
SMCFS801P
PoEPoE
DC
100BASE-TX UTP
100BASE-TX UTP With PoE
Power Line (DC)
PoE IP Camera
Non-PoE IP Camera
PoE Spiltter
PoEPoE
PoEPoE
PoE Wireless AP
PoE IP Phone
PoEPoE
