SMC Networks ISE20B User Manual

-11-
No.PS※※-OMV0006-D
●IO-Link indicator light operation and display
Communication
with master
IO-Link
indicator light
Status
Sub screen
display
∗1
Content
Yes
IO-Link
mode
Correct
Operate
Normal communication
status
(Reading of
measurement value)
Start up
When communication
starts up.
Preoperate
Abnormal
Version does not
match
Version of master and
IO-Link
does not match
∗2
Lock
Back-up and re-store
required due to data
storage lock
No
Communication
shut-off
Correct
communication
was not received for
1 second or more.
SIO mode General switch output
LCD display: “ ” OFF, “ ” Flashing, “ ” ON
∗1: “ModE - - -“ is displayed when selecting the modes on the sub screen.
∗2: When the product is connected to the master with version "V1.0", error Er15 is generated.
