•2 value display
The 2 value display function displays the items listed below on the right and left side of the sub display.
List of items for selection
Item Details
Sub display
Remarks
Left side
Right side
( ) Set value for OUT1 hysteresis mode ○ ○
When hysteresis mode is
selected
OUT1 hysteresis mode ○ ○
When hysteresis mode is
selected
( )
OUT1 Window comparator mode set value
(Lower side)
○ ○
When window comparator
mode is selected
( )
OUT1 Window comparator mode set value
(Upper side)
○ ○
When window comparator
mode is selected
OUT1 window comparator mode ○ ○
When window comparator
mode is selected
( ) Set value for OUT2 hysteresis mode ○ ○
When hysteresis mode is
selected
OUT2 hysteresis mode ○ ○
When hysteresis mode is
selected
( )
OUT2 Window comparator mode set value
(Lower side)
○ ○
When window comparator
mode is selected
( )
OUT2 Window comparator mode set value
(Upper side)
○ ○
When window comparator
mode is selected
OUT2 window comparator mode ○ ○
When window comparator
mode is selected
Pressure peak value
○
x
Pressure bottom value
x
○
Pressure display unit
○
○
Rated pressure range
○
○
OUT1 output mode/output style
○
x
OUT2 output mode/output style
x
○
NPN/PNP output set value
○
○
String of random characters
○
○
Display OFF
○
○
