Compact electro-pneumatic regulator
Series ITV0000
Cable connectors
Straight type and right angle type are available.
Built-in One-touch fitting
With error indication LED
Brackets
Flat and L-brackets are available.
Equivalent to IP65
Linearity within ±1%
(Full span)
Hysteresis 0.5% (Full span)
Repeatability ±0.5% (Full span)
High-speed response time 0.1sec
(Without load)
High stability
Stable pressure control is possible even when a metal cylinder is used.
Mist separator
(0.01 µm or less) (0.3 µm or less)
ITV (Electro-pneumatic regulator)
Air Filter
(5 µm or less)
IR
(Precision regulator)
W
Model
ITV001
ITV003
ITV005
ITV009
Pressure range
0.1 MPa
0.5 MPa
0.9 MPa
–100 kPa
Power supply
voltage
24 VDC
12 VDC
Output signal
Analog output
1 to 5 V
Option
• Cable connectors
Straight type
Right angle type
• Brackets
Flat bracket
L-bracket
Input signal
4 to 20 mA
0 to 20 mA
0 to 5 VDC
0 to 10 VDC
Flat bracket
L-bracket
Lightweight
100
g
Compact 15 mm
With a simplified high-density circuit board
design, an extremely compact size has been
achieved.
Stations can easily be
increased or decreased
due to DIN rail mount
design.
Realizes space-savings and
reduction of weight for manifold use.
Straight type Right angle type
Compact Electro-pneumatic Regulator
Series ITV0000
