SMCSM10-Z Smoke Alarm Guide
Copyright
©
2013 SMC Networks Page 9
All Rights Reserved
I/M SMCSM10-Z rev. 1.0
6/18/13
K. Reattach the SMCSM10-Z to its mounting
base.
L. Test the smoke alarm sensitivity and contact
the Central Monitoring Station to place the
system back online (remove from Test
mode).
M. Verify all auxiliary functions for a complete
test of the system.
Low Battery
Replace the batteries using the directions in
“Installing / Replacing Battery” in section 5.
15 Troubleshooting
The SMCSM10-Z does not power up properly or
reports low battery.
 Be sure the batteries are fully seated within
the battery compartment and the polarity is
correct.
 Check the battery voltage (3.0 VDC nominal).
Touchscreen does not respond.
 Follow the instructions in Section 9 to test
the SMCSM10-Z link with the Touchscreen.
 Be sure the SMCSM10-Z is enrolled into the
Touchscreen properly.
 Check with your Cable Operator to make sure
you are using an approved Touchscreen with
compatible software.
Tamper condition does not restore.
 Be sure the SMCSM10-Z is installed properly
onto the mounting plate and the mounting
plate has a magnet.
 Be sure there are no trouble indications at
the alarm.
 Check with your Cable Operator to make sure
you are using an approved Touchscreen with
compatible software.
If a tamper alarm occurs.
 Remove the SMCSM10-Z from its mounting
base and reinstall.
 Check with your Cable Operator to make sure
you are using an approved Touchscreen with
compatible software.
Alarm/open condition does not restore.
 Be sure the smoke or heat has cleared at the
SMCSM10-Z.
 Check with your Cable Operator to make sure
you are using an approved Touchscreen with
compatible software.
