7. Dimensions
2 x M6 x 1 thread depth 8
(Panel mounting screw)
Bracket plate thickness t = 2
Panel plate thickness t = 3 or less
R port
Supply pressure exhaust port
2 x 1/8 Output port 2( A )
Supply port on the other side 1( P )
ø4 EXH port
1/8
Input signal port( PIL )
2 x ø6.5 hole
(Mounting screw M6 x 1 x 12)
Panel mounted
Bracket mounted
Handle side
4 x M6 screw
4 x ø7 hole on the bracket side
