SME AC-X1 User Manual

ACX1_TAU_SYNC_UserManual_En
Page 8 of 37
SME S.p.A. Via della Tecnica 40 Z.I.
36071 ARZIGNANO (VI) ITALY
Phone +39 0444 470511 - Fax +39 0444 451803
sales@sme-group.com - www.sme-group.com
2.2 General Specifications
• Motor Type: AC Asynchronous/Synchronous 3-Phase
• Braking: Regenerative
• Modulation: PWM (Pulse Width Modulation)
• Switching Frequency: 9kHz
• Low R
DS,on
MOSFET
• 16 bits DSP controlling 1 AC motor
• Integrated Hall Effect Current Sensors
2.3 Electrical Specifications
2.3.1 Input and Output Ratings
Model Chart for 100V version
Model Name
AC Inverter Max Arms(2’)
Max Power(2’) at 100V
AC-X1 100V 250A 250 A
rms
29.3kVA
AC-X1 100V 375A 375 A
rms
44.0kVA
AC-X1 100V 500A 500 A
rms
58.7kVA
AC-X1 100V 625A 625 A
rms
73.1kVA
AC-X1 100V 750A 750 A
rms
88.1kVA

SME AC-X1 Specifications

General
