Smeg BCC02 User Manual

EN - 4
DISPOSAL
Electrical appliances must not be disposed
of with household waste. The appliances
that have this symbol are subject to
the European Directive 2012/19/EU. All
discarded electric and electronic appliances
must be disposed of separately from household
waste, by taking them to relevant centres
envisioned by the Country. By disposing of
the discarded appliance correctly, damage
to the environment and risks to health will be
avoided. For further information regarding
disposal of the discarded appliance, contact
the Municipal Administration, the Disposal
dept. or the shop where the appliance was
purchased.
DESCRIPTION OF THE APPLIANCE
(Fig. A)
1 Machine body.
2 Coffee bean container lid.
3 Coffee bean container.
4 Water tank cover.
5 Water tank (1,4 l).
6 Grinding selection knob.
7 Grinders protection.
8 Brewing group access door.
9 ON/OFF button.
10 Control panel.
11 Height adjustable coffee dispenser.
12 Coffee grounds container.
13 Internal drip tray.
14 External drip tray with level indicator.
15 Brewing group.
30 Steam wand.
31 Cleaning brush.
32 Steam wand cleaning needle.
33 Water hardness test strip.
IDENTIFICATION PLATE
The identication plate states the technical
data, serial number, and marking.
The identication plate must never be removed.
BEFORE FIRST USE
(Fig. A)
• Unpack the appliance carefully and remove
all packaging materials.
• Rinse the removable components with
lukewarm water, such as: water tank (5)
covers (2,4), door (8) grounds container
(12) drip trays (13,14) and brewing group
(15).
Before use, check that all
components are integral and have
no cracks.
ASSEMBLY OF COMPONENTS
(Fig. B)
• Place the machine on a at surface and x
the drip tray (14).
• Connect the power supply cable to the
socket on the rear of the machine and the
other end to a power socket .
DESCRIPTION OF CONTROLS
AND ALARMS (Fig. A-C-D)
ON/OFF button (9)
Pressing the button switches the machine on
or off.
Change dispensing program
button (20)
The product has 8 functions, accessible
through two menus, White Menu and Orange
Menu.
By pressing this button it is possible to change
the dispensing menu from “White” and
Description / Assembly / Controls

Smeg BCC02 Specifications

General

Product type	Espresso machine
Built-in grinder	Yes
Capacity in cups	1 cups
Grinder capacity	150 g
Coffee input type	Coffee beans, Ground coffee
Coffee maker type	Fully-auto
Country of origin	China
Appliance placement	Countertop
Water tank capacity	1.4 L
Maximum operating pressure	19 bar
Reservoir for brewed coffee	Cup
AC input voltage	220–240 V
AC input frequency	50 - 60 Hz
Auto power off after (max)	20 min
Package depth	265 mm
Package width	495 mm
Package height	445 mm
Package weight	7000 g
Quantity per pack	1 pc(s)
Cord length	1 m
Control type	Buttons
Product color	Red
Built-in display	No
Housing material	Aluminium, Plastic
Pallet weight	168000 g
Quantity per pallet	24 pc(s)
Pallet GTIN (EAN/UPC)	8017709301040
Quantity per pallet layer	6 pc(s)
Number of layers per pallet	4 pc(s)
Pallet net width	800 mm
Pallet net height	1900 mm
Pallet net length	1200 mm
Pallet net weight	120000 g

Weight and Dimensions

Depth	433 mm
Width	180 mm
Height	336 mm
Weight	5000 g
