3. Remove the drip tray (A11) and grounds container (g.
15).
4. Press the two red release buttons inwards and at the same
time pull the infuser outwards (g. 28).
Important! Do not use washing up liquid to clean the
infuser. It would remove the lubricant applied to the inside of
the piston, causing the infuser to seize up and become unusa-
ble.
5. Soak the infuser in water for about 5 minutes, then rinse
under the tap.
6. After cleaning, replace the infuser (A5) by sliding it onto
the internal support and pin at the bottom;
N.B.: If the infuser is dicult to insert, you must rst
adapt it to the right dimensions by pressing it forcefully from the
bottom and top as shown in the gure.
-
ped out.
8. Replace the drip tray (A11) and grounds container.
9. Close the service door (A2).
Cleaning the milk container
Important! Always clean the tubes inside the milk
container (B) when you prepare milk. If there is still milk in the
container, do not leave it out of the refrigerator for longer than
strictly necessary. Clean the container each time you prepare
1. Turn the milk container lid clockwise then remove it.
2. Remove the milk spout and intake tube.
Groove
Frothed milk regulator
3. Remove the frothed milk regulator by pulling it outwards.
4. Wash all the components thoroughly with hot water and
mild washing-up liquid.
and the groove on the ne end of the frothed milk regula-
tor.
5. Check that the intake tube and spout are not clogged with
milk residues.
6. Replace the frothed milk regulator, milk spout and intake
tube.
7. Replace the milk container lid.
CHANGING AND SETTING MENU PARAMETERS
After turning the
knob (C6) to the right or left and waiting
for the appliance to be ready, you can use the internal menu to
modify the following parameters and functions:
Support
Pin
Spout
Hole
Hole
