User instructions
28
Supports for cups and long objects
(ladles, spoons, etc.), in the rear;
can be tipped to the vertical
position when not in use.
Glass holder. Support for long-
stem glasses. When lifted out of
the stowed position (0) it snaps into
three different positions (1-2-3).
2-position fold-down supports (1-2).
In position 1 (vertical) they can be
used to take plates, while in position 2 (slanted) they provide support for
long-stem glasses which will be held in place by the glass holder.
Adjustment: raise point P as shown until the support turns into position 2.
