User instructions
1. Description of the controls
1.1 Front panel
All the dishwasher controls are grouped on the front panel.
1 ON/OFF
BUTTON
2 SELECTION PROGRAM
BUTTONS
(P1…P5)
3 ½ LOAD WASH
BUTTON (on some models only)
4 "3/1" OPTION
BUTTON (on some models only)
5 DELAY PROGRAM
BUTTON (on some models only)
6 START/STOP
BUTTON
7 POWER ON
LIGHT
8 PROGRAMS
INDICATOR LIGHTS
9
INFORMATION
DISPLAY
10
RECESSED DOOR HANDLE
1.2 Information display
The dishwasher is equipped with a practical
DISPLAY
which provides information on the
programmed dishwasher functions.
