The distance between the dryer and the moist air outlet
(ventilation shaft, window) should not exceed 2 meters,
otherwise water can accumulate in the tube.
B - Condensation dryer
• Moisture from laundry is extracted in the water condensation
device and is either collected in the receptacle or discharged
directly into the drain (drain height should not exceed 800mm).
• The signal light indicates that the container is full and should
be emptied, preferably after each drying cycle.
• Use the power cord to connect the dryer to the power supply
via wall socket.
• Rated voltage and other characteristics are indicated on the
name plate, located under the door frame of the appliance.
The wall socket should always be within reach. It has to
be earthed according to the standing regulations.
If the supply cable is damaged it should only be
replaced by a qualifi ed technician.
Power connectionPower connection
7
