EN-31-
•Theendofwaterdischargehosecanbettedtoaspe-
cicapparatusdirectlyattachedtodirtywaterdischarge
holeoroutletjointofthebasinelbow.
•Neverattempttoextendthewaterdischargehoseby
jointing.
•Donotputdischarginghoseofyourmachineinaves-
sel,bucketorsink.
•Makesurethatthewaterdischargehosedoesnot
bend,buckle,becrushedorextended.Pleasenote:
•Thewaterdrainhoseshouldbemountedataheight
maximum100cmfromtheground.
CHAPTER -3: INSTALLATION OF THE MACHINE
(WATER DISCHARGE CONNECTION)
~95cm ~140cm
~145cm ~95cm
0–max.100cm
˜
˜
95cm
150cm
