Instructions for the user
22
5. COOKING ZONES
REAR LEFT-HAND SINGLE PLATE
REAR RIGHT-HAND DUAL PLATE
FRONT LEFT-HAND DUAL PLATE
FRONT RIGHT-HAND SINGLE PLATE
REAR RIGHT-HAND OVAL PLATE
CENTRAL OVAL PLATE
FRONT LEFT-HAND SINGLE PLATE
The appliance features 4/5 cooking zones of different diameter and power. Their position is clearly
indicated by circles and the heat given off is defined by the markings on the glass surface.. The 5
cooking zones are of the HIGH-LIGHT type and come on after a few seconds of being activated.
Heating intensity can be adjusted by means of the knobs located on the front panel from a minimum
setting of 1 to a maximum setting of 6/9 (Depending on models).
The cooking zones marked by two concentric circles (
)and by a circle + fish-kettle ( / ) feature
double heating either within the inner circle or both circles.
