User instructions
24
LOADING THE UPPER BASKET
Load the dishes with the top side facing forwards; cups and concave
containers should always be loaded with the opening facing down. The
left side of the basket can be loaded with cups and glasses on two
levels. In the centre section, plates and saucers can be loaded vertically
into the supports provided.
Loading examples:
ADJUSTING THE UPPER BASKET
The upper basket can be adjusted in
two positions
, according to the
user’s needs and according to the height of the dishes in the lower
basket. Proceed as follows.
Pull-out
version:
•
pull out the right-hand basket guide
;
•
remove the stop, first releasing it as shown in the diagram
;
•
push the guide to free the wheels
;
•
fit the upper or lower pair of wheels into the guide, depending on the
setting required
;
•
return the stop to its original position
.
