Installation
41
EN
Overall dimensions
1
Minimum distance from the sides walls or
other flammable materials.
2
Minimum cabinet width (=A).
General information
This appliance may be installed next to
walls, one of which must be higher than the
worktop, at a minimum distance of 50 mm
from the side of the appliance, as shown in
figures A and C relative to the installation
classes.
Any wall units positioned above the
worktop must be at a minimum distance of
at least 600 mm. If a hood is installed
above the cooktop, refer to the hood
instruction manual to ensure the correct
clearance is left.
Depending on the type of installation, this
appliance belongs to classes:
A - Class 1 (Free-standing appliance)
A 900 mm
B 600 mm
C
1
500 mm
D 900 mm
H 750 mm
I 450 mm
L
2
900 mm
