SMITH SYSTEM LS 541N - Product Exploded View

Item # Part # Description Qty.
43 DB2E03811000U
Nylon Nut 3/8’’-16unc x 11t 29
44 P06-0165 Weight Stack / Guide Rod Bumper 2.50’’dia x 1.50’’ 4
45 P06-0233 Bumper 76.2 x 50.5 x 16h 2
46 P06-0246 Bumper 48 x 28 x 6.0t 4
47 P06-0247 Bumper 25.2 x 10t 2
48 P06-0249 Plastic Sleeve 50 x 25.2 x 343L 2
49 P08-0085 Step Spacer 16.2 x 10.1 x 12.5h 4
50 P08-0108 Step Spacer 16.2 x 10.1 x 9h 12
51 P08-0109 Step Spacer 16.2 x 10.1 x 14h 4
52 DI1080080U Snap Link 8 x 80L 2
53 P06-0051 3.5inch dia. Cable Pulley 22
54 A12-0049 Handle Strap 2
55 P13-0094 Lower Cable 4950mmL 2
56 P13-0093 Lat Cable 4474mmL 2
57 P11-0208 Selector Pin (Weight Plate) 2
Page5
Note: The " " mark before the item number refers to the part is pre-installed.
58 P10-0047
10lbs Weight Plate
18
59 P08-0037
Bronze Bushing 31.1 x 25 x 12h
2
60 P06-0024
Rectangular End Cap 38.1 x 63.5
2
61 A06-0325
Rectangular End Cap 44.45 x 101.6
7
62 P05-0240
Line Bearing
4
63 P06-0049
Square End Cap 38
2
64 P06-0252
Plastic Tube 40 x 25.2 x 59L
4
65 P12-0048
Non-Skip Pad 338W x 371L
1
66 P06-0187
Round End Cap 45
8
67 P06-0189
Bumper 76.2 x 5 x 16h
8
68 P06-0188
Plastic Tube 50 x 45 x 180L
8
69 P06-0253
Plastic Sleeve 50 x 75
2
70 P11-0034
Adjustment Knob
2
71 P08-0061
Bronze Bushing 19.45 x 12.8 x 15h
4
Parts Reference
Assembly Parts
