8 SERIES BOILER INSTALLATION AND OPERATING INSTRUCTIONS
Page 20
Table 4 - Boiler Parts
WATER AND STEAM BOILER PARTS LIST
1 6" Smokehood w/Gasket & Screws 71255 1 1
7" Smokehood w/Gasket & Screws 70023 1 1
2 Smokehood Gasket 60334 1 1 1 1
— Draft Plug 61518S
— Smokehood Mounting Screws (5/16") 61772 4 4 4 4
3 - 5 Burner Mounting Plate Complete Assy 70-1150 1 1 1 1
4A Sight Glass Holder 59472 1 1 1 1
4B Sight Glass 59471 1 1 1 1
4C Sight Glass Gasket 06-1008 1 1 1 1
— Sight Glass Screw 61757 2 2 2 2
5A Cleanout Door 3665 1 1 1 1
5B Cleanout Door Gasket 06-1009 1 1 1 1
5C Cleanout Door Insulation 05-1150 1 1 1 1
5D Cleanout Door Hinge 61335 1 1 1 1
5E Cleanout Door Hinge Screws 60820 2 2 2 2
5F Cleanout Door Roll Pin 608233 2 2 2 2
6 Insulation Block 61137 1 1 1 1
7 Wicking 1/4" (4ft Req'd) 60023 1 1 1 1
8 Floor Insulation Blanket 74310 1
74311 1
74312 1
74313 1
9 Target Wall 69406 1 1 1 1
10 Cleanout Cover Plate 14" X 8" 55458 1 2 1
Cleanout Cover Plate 14" X 12-1/2" 55459 1 1
11 Cleanout Cover Plate Insul 14" X 8" 65131 1 2 1
Cleanout Cover Plate Insul 14" X 12-1/2" 65132 1 1
12 Cleanout Cover Bolt (5/16") 60020 4 4 8 8
13 Cleanout Cover Washers (5/16") 62095S 8 8 16 16
14 Cleanout Cover Wing Nut (5/16") 60871S 4 4 4 4
15 Cleanout Cover Jam Nut (5/16") 60881S 4 4 8 8
NUMBER OF SECTIONS
Ref # Name of Part Part No. 3 4 5 6
