Table 4 - Boiler Parts
continued
NUMBER OF SECTIONS
Ref # Name of Part Part No. 3 4 5 6
DIRECT VENT
16 Water Block - DV-8 70-1083 1
70-1084 1
A Cleanout Cover 55458 1
55459 1
B Cleanout Cover Gasket 06-1005 1
06-1006 1
C Cleanout Cover Frame 03-1070 1
03-1071 1
— 4" Insulated Vent Pipe 15' 09-1102 1 1
— 4" Direct Vent 09-1101 1 1
WATER BOILER PARTS
— Complete Jacket 70247 1
70248 1
70249 1
70250 1
16 Water Block 70111 1
70112 1
70113 1
70114 1
17 Hydrolevel Aquastat/LWCO 14-0009 1 1 1 1
Hydrolevel Electrostatic Well for LWCO 14-0008 1 1 1 1
18 Relief Valve 30# (Water, Female Thread) 61988 1 1 1 1
19 Temp & Pressure Gauge 60265 1 1 1 1
20 Bushing 1" X 1-1/14" 61161S 1 1 1 1
21 Heater Cover Plate 3667 1 1 1 1
22 Tankless Heater, Water (3.5 GPM) 70009 1 1
Tankless Heater, Water (5.0 GPM) 70010 1 1
23 Heater Plate Gasket EPDM (Water & Steam) 60248S 1 1 1 1
STEAM BOILER PARTS
— Complete Jacket 55404 1
55405 1
55406 1
55407 1
24 Universal Block 70272 1
70273 1
70274 1
70275 1
25 Steam Pressuretrol PA404A 50493 1 1 1 1
26 Tankless Ctrl L4007 50510 1 1 1 1
27 LWCO Less Tankless: CG450-20/60 50086 1 1 1 1
LWCO With Tankless: CGT450-20/60 50087 1 1 1 1
— Optional: #67 LWCO 50763 1 1 1 1
28 Bushing 1" X 1-1/4" 61161S 1 1 1 1
29 Relief Valve 15# (Steam, Male Thread) 61980 1 1 1 1
30 Gauge Glass Set 60289 1 1 1 1
31 Steam Gauge 60268 1 1 1 1
32 Tankless Heater (3.5 GPM) 70011 1 1 1 1
33 Heater Plate 69778 1 1 1 1
34 Heater Plate Gasket 60336 1 1 1 1
35 Heater Cover Plate w/Skim Tapping 3579 1 1 1 1
