Smith GBX 70 - Jacket

INSTALLATION AND OPERATING INSTRUCTIONS
Figure 11.5:Jacket
Table 11.5: Jacket
38
Item
No.
Description
Part Selection
Information
70 105 140 175 195
16 Jacket Assembly Complete jacket* with
insulation and screws
90445 90446 90447 90448 90449
16
16
16
16
16
16
*Complete Jacket Consists of:
Left Side Panel
Right Side Panel
Rear Panel
Top Upper Front Panel
Inner Front Baffle Panel
Removable Front Panel
