TRAK MODEL 9100 MODULAR FREQUENCY/TIME SYSTEM
2-9
TM4400013 Rev. D
Table 2-12, Model 9111 TEL RS-422 Clock Outputs, J1
Pin
No FUNCTION
Pin
No FUNCTION
1 Output A, + 6 Output A, -
2 Output B, + 7 Output B, -
3 Output C, + 8 Output C, -
4 Output D, + 9 Output D, -
11- 15 Ground 5-10 No Connection
Table 2-13 Model 9111 TEL Framed Outputs, J2
Pin
No FUNCTION
Pin No
FUNCTION
1 Output A, + 6 Output A, -
2 Output B, + 7 Output B, -
3 Output C, + 8 Output C, -
4 Output D, + 9 Output D, -
11- 15 Ground 5-10 No Connection
