TRAK MODEL 9100 MODULAR FREQUENCY/TIME SYSTEM
TM4400013 E-7 REV. D
Coaxial Cable and Accessories Selection
2-0 General
50 feet of RG-58 type coaxial cable is supplied as standard with every GPS model. If a length greater than 50
feet or non-RG-58 cable is required, options are available. A 20 dB line amplifier is available when using long
cable runs, consult factory for special applications and considerations.
2-1 Available Antenna Cable Options
The common available antenna cable options and accessories are shown in Table 1. If a longer cable is
required, consult factory for cable type and GPS line amplifier (if required).
Table 1, Standard Coaxial Cable Options
Antenna
Option
Option
No.
Description
Used On
1001661-131 L9A Antenna & mast adapter, TNC connector, 12VDC Note 1
1001661-209 L10A
L9A & 50’ RG-58
Note 1
1001661-210 L11A L9A & 100’ RG-213
Note 1
1001661-221 L22A L9A & 250’ Belden 9913
Note 1
1001661-222 L23A L9A & 2 x 250’ Belden & 20 dB amp
Note 1
1001661-227 L28A L9A & 2 x 200’ Belden 9913 & 20 dB amp
Note 1
1001661-150 L50 ¼” Andrews TNC- 50’ w/ spare TNC connector Note 1
1001661-151 L51 ¼” Andrews TNC- 100’ w/ spare TNC connector Note 1
1001661-152 L52 ¼” Andrews TNC- 200’ w/ spare TNC connector Note 1
1001661-157 L9N Antenna & mast adapter, “N” connector, 5 VDC Note 2
1001661-158 L70 L9A & L60 & L51 & L61 (100’ cable)
Note 1
1001661-159 L71 L9A & L60 & L50 & L61 (50’ Cable)
Note 1
1001661-156 L72 L9A & L60 & L52 & L61 (200’ Cable)
Note 1
1001661-160 L60 Lightning /surge suppressor (TNC-TNC) Note 1
1001661-161 L61 ¼” Andrews grounding kit Note 1, Note 2
1001661-162 L62 ¼” Andrews cutting tool Note 1, Note 2
1001661-163 L50N ¼” Andrews N- 50’ w/ spare N connector Note 2
1001661-164 L51N ¼” Andrews N- 100’ w/ spare N connector Note 2
1001661-165 L52N ¼” Andrews N- 200’ w/ spare N connector Note 2
1001661-166 L60N Lightning /surge suppressor (N-N) Note 2
1001661-167 L70N L9N & L60N & L51N & L61 (100’ cable)
Note 2
1001661-168 L71N L9N & L60N & L50N & L61 (50’ Cable)
Note 2
1001661-169 L72N L9N & L60N & L52N & L61 (200’ Cable)
Note 2
4700012
------
20 dB GPS Line Amplifier, TNC connectors Note 1
Note 1: These assemblies are designed for the 12 volt, TNC connector series which include; 8812, 8820A,
8821, 8900, and 9000.These units Use the L9A antenna, 4.5 to 15 VDC. Standard Antenna Option for
these Models unless otherwise specified 1001661-209
Note 2: These assemblies are designed for 5 Volt, “N” connector series, which include the 9100. These units
use the L9N antenna option. Standard antenna option for these models unless otherwise specified is
1001661-157 (L9N) & 1001661-163 (L50N)
Note 3: Bold options are complete antenna & cable options.
