Smithy MI-329M - Main Specifications

MAIN SPECIFICATIONS
Model MI-329M
Work Area Requirements 73” x 50-1/2”
T-Slot Size 5/8”
Table Size 31.5” x 9.3”
Column Dovetail Ways
Draw Bar Size 7/16-20
Drill Chuck Size (Included) 1/2”
Drill Chuck Arbor (Included) R8/JT33
Rotating Mill Head 90 Degrees (Left and Right)
Head Travel 15”
Quill Travel 5”
Quill Diameter 3”
X-Axis Travel 22”
Y-Axis Travel 7.25”
Spindle Taper R8
Spindle Speeds 95, 175, 310, 450, 850,150095, 175, 310,
450, 850,1500
Spindle to Table (Distance) 3.25” to 18.25”
Spindle Center to Column 9.5”
Dial Calibration Drill - Coarse Feed N/A
Dial Calibration Mill - Fine Feed .001”
Dial Calibration X-Axis .001”
Dial Calibration Y-Axis .001”
Powerfeed (X Axis) Optional
Powerfeed (Z Axis) None
Oiled Gear Boxes Yes
Oil Type SAE 30
MAXIMUM TOOL SIZE
Model MI-329M
Drill 1”
Face Mill 3”
End Mill 1”
Tapping 1/2”
