MAIN SPECIFICATIONS
Work Area Requirements 73” x 50-1/2”
T-Slot Size 5/8”
Table Size 40” x 9-3”
Column Dovetail Ways
Draw Bar Size 7/16-20
Drill Chuck Size (Included) 5/8”
Drill Chuck Arbor (Included) R8/JT3
Rotating Mill Head 45 Degrees (Left and Right)
Head Travel 15”
Quill Travel 5”
Quill Diameter 3”
X-Axis Travel 30”
Y-Axis Travel 7.25”
Spindle Taper R8
Spindle Speeds 95, 175, 310, 450, 850,150095, 175, 310,
450, 850,1500
Spindle to Table (Distance) 2.5” to 16.5”
Spindle Center to Column 10”
Dial Calibration Drill - Coarse Feed .045”
Dial Calibration Mill - Fine Feed .001”
Dial Calibration X-Axis .001”
Dial Calibration Y-Axis .001”
Powerfeed (X Axis) Yes
Powerfeed (Z Axis) Yes (Spindle)
Oiled Gear Boxes Yes
Oil Type SAE 30
MAXIMUM TOOL SIZE
Drill 1”
Face Mill 3”
End Mill 1”
Tapping 1/2”
12
