Snap-On ATECH2CS240 User Manual

6
Note: Head length entered is offset length measured from center of drive to center of fastener.
Use of Negative Offsets
Note: Enter a negative value for offset when used in reverse direction.
When length of an offset is negative, maximum fastener target is limited by following formulas:
240 in-lb wrench:
Maximum Target Torque = offset * 24 + 240
100 in-lb wrench:
Maximum Target Torque = offset * 7 + 100
Offset
Max Target
Offset
Max Target
-1"
216 in-lb
-1"
93 in-lb
-2"
192 in-lb
-2"
86 in-lb
-3"
168 in-lb
-3"
79 in-lb
-4"
144 in-lb
-4"
72 in-lb
Note: When using a negative offset, entering a target torque greater than maximum values above
may cause an overtorque error before reaching fastener target torque and possibly damage
wrench.
Viewing Stored Torque and Angle Data
Torque data is stored in memory after each torque cycle if applied torque has reached target value.
Torque and angle data is stored in memory after each angle cycle if applied angle has reached target
value. Memory Indicator is displayed when data is stored in non-volatile memory.
1. To view stored torque and angle data, from target torque or angle screen, press and hold ENTER
  button for 3 seconds.
2. Highlight SHOW DATA menu selection by pressing UP   /DOWN   buttons then press
ENTER   button to display Show Data screen. To view stored torque and angle data, from target
torque or angle screen, press and hold ENTER   button for 3 seconds.
3. Highlight SHOW DATA menu selection by pressing UP   /DOWN   buttons then press
ENTER   button to display Show Data screen.
4. In Show Data screen, scroll through each stored data record by pressing UP   /DOWN   buttons.
Example: 02 = Show Data List Counter: TQ = Peak torque value
01 = Show Data List Counter: TQ = Peak torque value: ANG = Peak angle value
5. Pressing ENTER   button while on Show Data screen returns to main menu.
𝑜𝑓𝑓𝑠𝑒𝑡
𝑜𝑓𝑓𝑠𝑒𝑡
