ZBJP1B rev B 06/11/2014
Ball Joint Press Component Assembly
Slide sleeve adapter (BJP1-1A) into hole of press frame (BJP1F) and secure with
retaining ring (ME7A207) as shown in FIG. 3. Use snap ring pliers with proper tip
size. Thread grease fitting (BJP1-17) into tapped hole of press frame as shown using
5/16” socket.
WARNING
Maintenance
The pressure screw threads need to be wiped clean and re-lubricated with chassis
grease on a regular basis. Use grease fitting (installed on screw side arm of frame)
to apply grease to the screw threads.
BJP1 - Operating Information
The BJP1 ball joint master set is designed to be used without removing the control
arm from the vehicle on most cars and trucks that have press-fit type ball joints.
NOTE: Some vehicles have the upper ball joint spot-welded to the control
arm. The weld must be cut before attempting to remove the ball joint.
