8
ZCTR714ACE Rev. E (08/19)
DO NOT THROW IN GARBAGE
BC
CALIFORNIA - TITLE 20
COMPLIANT
Battery Pack
Specifications
DO NOT USE CTB6172
FULLY CHARGE BATTERIES BEFORE INITIAL USE
Type
CTB8172BK/CTB8174 ........................ Lithium-Ion
Voltage
CTB8172BK/CTB8174 ...........................................
..................................... 14.4 VDC (3.6 V x 4 cells)
Weight
CTB8172BK/CTB8174 ...............~0.51 lbs (.23 kg)
Charge Time
CTB8172BK .............................................~55 min
CTB8174 .................................................. ~70 min
Life
CTB8172BK/CTB8174 ........................1000 cycles
Note: 1 cycle=1 charge and 1 discharge
Capacity
CTB8172BK ..............................................2.0 A•H
CTB8174 ................................................... 2.5 A•H
Discharge Temperature Range
CTB8172BK/CTB8174 ...........................................
................................. -4°F(-20°C) to 140°F(60°C)
Battery Charger
Specifications
Input
CTC772A/CTCA772A/CTCEU772A/CTCJ772A .......
........................................ 100-240 VAC, 50/60 Hz
Output
All Models .....................................................3.0 A
Weight
All Models ...............................~1.15 lbs (0.52 kg)
Charging Temperature Range
CTB8172BK/CTB8174 ...........................................
.................................... 32°F(0°C) to 113°F(45°C)
DO NOT BLOCK VENT OPENINGS!
Application
The Snap-on CTR714A/CTRQ714/CTR717/CTRQ717
Cordless Ratchet is a rugged, reversible ratchet that is
ideal for many confined automotive and industrial
applications.
It is designed and built to make fast work of light duty
fastener turning jobs that do not require more than 35 ft.
lb. (47 N•m) torque.
Drive Bits
Use only Insert Bits (1” or shorter) with the CTRQ714/
CTRQ717. Recommended sets include:
• SDMC8P – 8 pc, includes GMB3041 hex to ¼” square
drive adapter, black case
• SDMC8GP – 8 pc, includes GMB3041 hex to ¼” square
drive adapter, green case
• SDMC8OP – 8 pc, includes GMB3041 hex to ¼” square
drive adapter ,orange case
• SDMC8RP – 8 pc, includes GMB3041 hex to ¼” square
drive adapter, red case
DO NOT use Power Bits with the CTRQ714/CTRQ717.
Variable Speed Trigger
This tool is equipped with a variable speed trigger which
allows precise output speed control.
Reverse Mechanism
The direction of rotation is determined by the position of
the selector knob in the ratchet head. Be sure the selector
knob is positioned fully in either direction before
depressing the paddle. Turning the selector knob
counterclockwise turns the nut or bolt in a clockwise
direction.
Ratchet Mechanism Lubrication
If the cordless ratchet receives daily, steady workouts,
the ratchet mechanism should be greased daily. Adjust
the lubrication schedule according to the usage. Using a
Snap-on YA4190CAP Grease Gun, or similar type
grease gun, inject grease through the flush-type fitting in
the reverse mechanism until fresh grease becomes
visible. Use a grease such as Snap-on ME18A15 Ratchet
Grease or an equivalent type.
Order YA4190FAR (includes YA4190CAP and
YA4190DIS)
