Snap-On MODIS Edge Quick Start Guide

Measure waveforms, test circuits and components using the built-in
lab scope, graphing multimeter (GMM), or digital multimeter (DMM).
Pre-configured tests include these and more!
• Volts DC
• Volts AC RMS
• Ohms
• Diode Continuity
• Frequency
• Injector Pulse Width
• Duty Cycle
• Low Amps (20,40 and 60)
• Pressure and Vacuum
• Pulse Width
(2-Channel)
Scope / Multimeter
Quickly access global OBD-II/EOBD codes, tests, and data without having
to identify the vehicle.
• OBD Direct - access OBD-II/EOBD service modes (e.g. $01 to $0A), allowing you to
view current diagnostic trouble codes, parameter data, freeze frame information,
O2 sensor monitoring test results, check calibration numbers, and more!
•
OBD Di
re
OBD-II/EOBD
Save setup time when re-testing a vehicle, and review your saved files.
• Vehicle History - lists the last twenty-five vehicles selected.
• View Saved Data - lists all saved data files, including screen images.
• Delete Saved Data - permanently erases saved files from memory.
•
Vehicle
H
Previous Vehicles and Data
• OBD-II Health Check - quickly check or clear diagnostic trouble codes, check
readiness monitor status, and MIL status.
Easily change settings to your preferences, and transfer saved data files
to your PC.
• Connect-to-PC - transfer saved data files to your PC using a USB cable and
ShopStream Connect™.
• Configure Shortcut Button - change the function of the Shortcut button to one of
five options.
• Settings - adjust display and unit measurement settings to your preferences.
• System Information - displays software version, serial number and system
information.
•
Connect
Tools
