Snap-On Sun SWB 200 - Layout

14
4-1
3
1
4-2
2
1
2
3a
4
6
7
9
5
8
3b
Layout
4.0 Layout
Refer to Figure 4-1.
Functional description of the unit:
1. monitor
Refer to Chapter 4.1.
2. Input panel
Refer to Chapter 4.2.
3a Internal gauge arm
3b External Detector - Sonar (where provided)
4. Flange
5. Stub shaft
6.
Weight compartments
7. Storage areas for cones and hub nuts
8. Wheel guard
9. Wheel Brake
Refer to Figure 4-2.
1. Mains switch (ON/OFF)
2. Fuse holder
3. Power inlet
