18
4. Press ENTER   button to accept selection and exit to Mode Setup menu.
Note: Menu selection indicates current configuration (ENABLED or DISABLED).
Torque THEN Angle Mode
Torque THEN Angle mode is setup by first setting a target torque and units then a target angle before
selecting Torque THEN Angle mode. In Torque THEN Angle mode, when applied torque reaches target
torque, wrench automatically switches to angle mode for angle measurement. Progress lights indicate
applied torque progress while torque is measured and angle when angle is measured.
1. From target torque screen, use UP   /DOWN  buttons to set target torque and UNITS U button
to select torque measurement units then press ENTER   button.
2. Angle target screen is displayed. Use UP   /DOWN  buttons to set target angle then press
ENTER   button.
3. Torque THEN Angle mode screen is displayed.
4. Apply torque until target is reached then rotate wrench to target angle.
Note: UNITS U button can be used to select torque units while on Torque THEN Angle screen.
Note: Torque THEN Angle Presets are entered by pressing and holding Units button while on Torque
THEN Angle screen. Refer to "Adding a Torque Preset" and "Adding an Angle Preset" in Basic
section for parameter entry.
Note: Torque cycle is not recorded in memory unless both torque and angle reach targets.
Note: Red and yellow progress lights turn on if torque exceeds 110% of wrench full scale or if angle
exceeds target plus 4% in manual mode.
Note: Red and yellow progress lights turn on if torque exceeds maximum torque or if angle exceeds
maximum angle in Preset mode.
Delete All Presets
Delete Presets function allows user to delete all presets at once.
1. From Configure menu, use UP   /DOWN  buttons to highlight DELETE PRESETS selection then
press ENTER   button.
2. Delete Presets confirmation screen is displayed.
3. Use UP   /DOWN  buttons to select YES or NO selection.
4. Press ENTER   button to accept selection and exit to Configure menu.
EXIT
THEN DISABLED
TQ THEN ANGLE
ENABLE
DISABLE
ENTER
button
UP/DOWN buttons
TQ THEN ANGLE
ENABLE
DISABLE
ENTER
button
ENTER
button
EXIT
THEN ENABLED
EXIT
THEN DISABLED
UP/DOWN buttons
00
45°
UP/DOWN buttons
ENTER
button
00
TQ: 100.0 FT-LB
THEN AN: 45°
00
100.0
FT-LB
ENTER
button
Torque THEN Angle Screen
