Editing a Preset
Edit PSET function gives user ability to edit stored PSETS on wrench.
1. From Preset screen to be edited, press and hold UNITS U button for 3 seconds.
2. CHANGE PRESET screen is displayed.
3. Highlight EDIT selection using UP   /DOWN   buttons then press ENTER   button.
4. MINIMUM TORQUE or ANGLE screen is displayed. Value can be changed by pressing UP   /DOWN
 buttons. Once desired target torque or angle value has been set, press ENTER   button.
5. MAXIMUM TORQUE or ANGLE screen is displayed next. Value can be changed by pressing UP  
/DOWN   buttons. Once desired target torque or angle value has been set, press
ENTER   button.
6. BATCH COUNT screen is displayed next. Value can be changed by pressing UP   /DOWN  
buttons. Once desired batch count value has been set, press ENTER   button.
7. PSET target screen is displayed labeled with same PSET number.
Note: Pressing ENTER   button while EXIT menu selection is highlighted will exit without editing
PSET.
Deleting a Preset
Delete PSET function allows user to remove stored presets from wrench.
1. From Preset screen to be deleted, press and hold UNITS U button for 3 seconds.
2. CHANGE PRESET screen is displayed.
3. Highlight DELETE menu selection using UP   /DOWN   buttons and press ENTER   button.
4. Target screen is displayed and deleted PSET is no longer available for selection.
Note: Pressing ENTER   button while EXIT menu selection is highlighted will exit without deleting
PSET.
Note: When a PSET is deleted, all other stored PSET’s will retain their original PSET numbers. When a
new PSET is entered, it will be assigned first available PSET number in sequence.
BATCH COUNT
0
ENTER
button
UP/DOWN buttons
CHANGE PRESET
DELETE
EDIT
EXIT
PSET 02 00
92°
UNIT
button
held
Preset Angle Screen
UP/DOWN buttons
ENTER button
PSET 02 01
of
04
90°
Preset Angle Screen
CHANGE PRESET
DELETE
EDIT
EXIT
ENTER
button
UP/DOWN buttons
MINIMUM ANGLE
92°
MAXIMUM ANGLE
94°
UP/DOWN buttons
ENTER
button
00
100.0
FT-LB
CHANGE PRESET
DELETE
EDIT
EXIT
UNIT
button
held
Target Screen
UP/DOWN buttons
ENTER button
PSET 02 00
92°
Preset Angle Screen
CHANGE PRESET
DELETE
EDIT
EXIT
ENTER button
