Snapmaker Enclosure - Step 4: Connect Main Frame Pieces

Assemble the Enclosure
10
Guide for Enclosure
1
2
3
4
Connect the four frame pieces to the corner
brackets of the bottom as illustrated
4
Take 2 frame pieces with bulges and attach them to
corners 1 and 3. Attach the frame piece with magnets to
corner 4 and the last piece to corner 2.
12
34
Notice
Position the assembled part as illustrated.
Frame Piece x 1
M4 x 4 Screw
x 4
Frame Piece with Magnets x 1
Frame Piece with Bulges x 2
Frame Piece with Magnets
1:1
