Manual No.
710475722" VARIABLE SPEED HIGH WHEEL
11
Mower Deck Group
Part No Descri
p
tionItem Qty
1 7600156 1 DECK, 22” Front Wheel Drive, Washout
2 7301091BH 1 BRACKET, Lower Handle, LH, Hi-Wheel
3 7301090BH 1 BRACKET, Lower Handle, RH, Hi-Wheel
4 7103299 1 CHUTE, Side Discharge, 22” WBM
5 7091020 3 PUSHNUT, 1/4”
6 7300855BM 1 BRACKET, Chute
7 722507 1 CHUTE SPRING, Torsion
8 7900067 6 SCREW, 1/4-20 x .550” Pan Head Torx (T-30)
9 7101067 1 ROD, Pivot
10 7103298 1 COVER, Mulching
11 7502426 1 COVER, SPX, Front Wheel Drive (Replaces Cover 7104780, Shield 7104172)
12 720182 1 PLUG, Panel, .25 x .61L, Black
13 7900079 1 NUT, 3/16” Push
14 7900018 2 SCREW, 4.8 x 1.59 x 13mm, Round Washer Head Hi-Lo (Torx)
15 7301020 1 BAFFLE, Front, Galv.
16 7023295 4 U-NUT, 1/4-20
17 7090803 3 BOLT, 1/4-20 x 5/8” Flat Head Square Neck, GR 5
18 7103452 1 REAR BAFFLE, Front Wheel Drive, WBM
19 1960593 2 SPEED NUT, #10-24 Retainer w/Extrusion
20 7091075 2 SCREW, #10-24 x 5/8” Hex Washer Face Self-Tap, GR 5
21 7090699 4 BOLT, 1/4-20 x 3/4” Hex Flange Lock, GR 5
22 7900073 2 BOLT, Drag Shield, 1/4-20 x 1-1/2”
23 7103453 1 PLUG, Mulching, 22” Deck
24 7103323 1 GUARD, Rear, 22”
25 1960518 3 RETAINER, 1/4” Bolt
26 722398 3 NUT, 1/4-20 Hex Flange Lock
27 7501541 1 ASSEMBLY, Door, 22” WBM (Incl. #'s 5, 28, 29, 30 & 31)
28 7103291 1 DOOR, Rear Discharge
29 7103322 1 ROD, Pivot, Rear Door
30 7103309 1 SPRING, Torsion, Rear Door
31 7103292 1 DOOR HINGE, Rear Discharge
32 7103957 1 WASHER, Hose
33 7103804 1 ADAPTOR, Washout Port, WBM
34 7103919 1 COUPLING, Hose
35 7091546 1 WASHER, 5/8” Internal Tooth Lock YZ (Was 7090880)
36 1960716 1 NUT, 5/8-11, NC-2B Black Hex Jam
