Manual No.
710475722" VARIABLE SPEED HIGH WHEEL
13
Wheels Group
Part No Descri
p
tionItem Qty
1 7101393 2 HUBCAP, 12” Wheel, Snapper Cool Gray
2 7091585 6 NUT, 3/8-16 Hex Center Lock, GR 5, YZ
3 722604 4 WASHER, 1” O.D. x .387 I.D., Flat
4 7104181 2 WHEEL, 12” x 2” w/Snapper Tread, Snapper Cool Gray
5 7500542 2 ASSEMBLY, Wheel, 8” x 2” Drive w/Snapper Tread, Charcoal Gray (incl. two 7101380 Ball
Bearings)
6 7101207 2 GEAR, Pinion, 22” WBM, Front Wheel Drive
7 7091331 2 WASHER, 13/32 x 1-1/2” x .120 Flat, YZ
8 7501639 2 ASSEMBLY, Rear Wheel Bracket, Hi-Wheel (staked)
9 7103301 2 LEVER, Front, Height-Of-Cut, 22”
10 7103793 4 GRIP, Height Latch, Black
11 722611 2 WASHER, Belleville, 1.01-1.64
12 7103511 2 BUSHING, Pivot, Hi-Wheel, Rear
13 7091591 4 BOLT, 5/16-18 x 1” Hex Flange lock, GR 5, YZ
14 1931277 4 NUT, 5/16-18 Hex Flange Lock, GR 5, YZ (Was 7091601)
15 7091790 2 BOLT, 3/8-16 x 1-1/4” Round Head Square Neck Carriage, GR 5 YZ
16 7101350 2 HUBCAP, 8” & 9” Spoked Wheel, Snapper Cool Gray (Was 7102507)
17 7101270 2 DRIVE PIN, 22” WBM
18 7014341 4 RETAINING RING, .392 Ext.
19 7900067 4 SCREW, 1/4-20 x .550” Pan Head Self-Tap (Torx)
20 7101402 2 SHIELD, Dust, 22” WBM, Front Wheel Drive
21 7600105 1 ASSEMBLY, Height-of-Cut, LF, 22” WBM, Propelled
22 7600104 1 ASSEMBLY, Height-of-Cut, RF, 22” WBM, Propelled
23 7091584 4 NUT, 1/4-20 Hex Flange Lock, YZ
