Manual No.
710475722" VARIABLE SPEED HIGH WHEEL
7
Drive Control Assembl
y
Part No Descri
p
tionItem Qty
1 7091075 1 SCREW, #10-24 x 5/8” Hex Washer Self-Tap
2 7091195 4 SCREW, #10-16 x 3/4” Pan Head Self-Tap, Combo
3 1960593 1 NUT, #10-24 Retainer Speed w/extrusion
4 7102803 2 LEVER, Drive Control
5 7102804 2 LEVER, OPC, Control
6 7102805 1 CAM, Drive, LH
7 7102806 1 CAM, Drive, RH
8 7103325 1 CONTROL PANEL, Bottom, MY Mower
9 7103326 1 PANEL, Bottom Control, WBM, RH
10 7103327 1 PANEL, Bottom Control, WBM, LH
11 7103456 1 PANEL, Access, Maintenance Reminder
12 7104294 1 PANEL, Top Control
13 7104689 1 SPRING, Tension, Drive Control
14 7104752 1 CABLE, OPC, 2010 NXT
15 7105086 1 CABLE, Drive Control, 2010 NXT FWD (Was 7104296)
16 7900081 4 SCREW, #10-16 x 2” Hi-Lo Cross Pan Head 7800776 & 7800779
