Manual No.
710475722" VARIABLE SPEED HIGH WHEEL
9
Engine Group
Part No Descri
tionItem Qty
1 7900072 3 SCREW, 3/8-16 x 1-1/4” Hex Washer Self-Tap
2 7103517 2 BELT GUIDE, Engine, FWD
3 7100437 1 PULLEY, Engine
4 7092086 1 SET SCREW, 5/16-18 x 1/2” Hex Recess
5 7091214 1 KEY, # HP-506 Hi-Pro
6 7101414 1 BLADE HUB, 21” WBM, RD, 2 Position
7 7103288BZ 1 BLADE, Wave, Steel Deck
8 7012063 1 WASHER, Cone 13/32x1-13/32” Dia.
9 7090167 1 SCREW, 3/8-24 x 2” Hex Head Cap, GR 5
10 7103305A 1 BAG FRAME, Rear Discharge (weldment)
11 7103375 1 GRASS BAG, 22” Rear Discharge
12 128T02-0740-B3 1 * ENGINE, B&S, 700 Series, B3, X-Spec (Used on 7800776)
12 128T02-0115-F1 1 * ENGINE, B&S, 700 Series, F1, X-Spec (Used on 7800779)
NOTE: * Purchase engine parts from engine manufacturer dealer.
