Snapper 7800923

Assembly & Set-Up
3
9
Assembly
NOTE: This unit is shipped without gasoline or oil in the engine.
Fill up with gasoline and oil as instructed BEFORE operating your
mower.
Handle
1. Remove any packing material which may be between
upper and lower handles.
a. Remove wing nuts and carriage bolts from handle
as shown in Figure 3-1. Do not loosen or remove
adjacent hex head screws.
A
A
Figure 3-1
b. While stabilizing mower so it doesn’t move, pivot

crimp cable while lifting the handle up.
B
Figure 3-2
Contents of Carton
 One Lawn Mower  One Grass Catcher  One Bottle of Oil
 One Operator’s Manual  One Side Discharge Chute
