250 Z & Javelin Series
TP 300-5241-00-HZ-SN
10/20068
Check
Fluid Levels
Fill & Check Engine Oil
Removing the rear cover to gain access to the
engine, use the dipstick (A, Figure 3) to check the
engine oil level. If necessary add engine oil. Check
engine manufacturer’s owner’s manual for oil recom-
mendations.
Figure 3. Check Engine Oil Level
A. Engine Oil Dip Stick
Figure 4. Tire Pressures
Tire Pressure
Front 25 psi (1,72 bar)
Rear 15 psi (1,03 bar)
Reduce & Check Tire
Pressures
The tires are over-inflated for shipping purposes. Inflate
to the pressures shown. Note that these pressures may
differ slightly from the “Max Inflation” stamped on the
side-wall of the tires. The pressures shown provide prop-
er traction, improve cut quality, and extend tire life.
A
To Next Page
