Section 1 - FAMILIARIZATION
FIGURE 1
1.1 INTRODUCTION: This manual covers the recommended operating procedure and
routine service requirements on SNAPPER Intermediate Rear Tine Tiller Model IR5003B.
It is recommended that all operator’s of this Tiller become thoroughly familiar with the
controls and proper operation of the unit before operating. Specific details involving the
engine are found in the separate engine owner’s manual. Study these manuals before
operating and keep both handy for future reference. Refer to Figure 1 above for location
of controls and other essential components.
HANDLEBAR
WHEEL & TINE
CONTROL BAIL
SHIFT COVER
THROTTLE CONTROL
ENGINE AIR FILTER
CHOKE CONTROL
HANDLE
BRACKET
WHEEL & TINE
SHIFT LEVER
ENGINE
DRIVE
BELT
GUARD
ENGINE OIL
CHECK/FILL
PLUG
OIL DRAIN
PLUG
WEIGHT
BOX
STAND-UP
BAR
TRANSMISSION
CHAIN CASE
TIRE & WHEEL
STARTER ROPE
TINE
MAIN CASE
FILL PLUG
DRAG
SHIELD
TINE
COVER
DEPTH
BAR
DASH
PANEL
CLUTCH
CABLE
COVER
LEFT SIDE SHOWN TO
VIEW CHECK PLUG
MAIN CASE GREASE
CHECK PLUG
