10
ACCESSORY, ANTI-SCALP 6-0737
ITEM PART NO. DESCRIPTION
-- 6-0737 KIT, Anti-Scalp Wheel (33” Decks) (Includes items 1 thru 6)
1 3-2478 BRACKET, Wheel (2)
2 1-9190 WHEEL (2)
3 1-5272 SPACER (2)
4 9-0859 SCREW, 3/8-24 x 3-3/4” Hex Head Cap, Grade 5 (2)
5 9-0289 NUT, 3/8-24 Hex Center Lock (6)
6 9-0292 SCREW, 3/8-24 x 3/4” Hex Head Cap, Grade 2 (4)
ACCESSORY, ANTI-SCALP 6-0794
ITEM PART NO. DESCRIPTION
-- 6-0794 KIT, Anti-Scalp Wheel (41” Decks) (Includes items 1 thru 7)
1 4-7913 BRACKET, R.H.
2 4-7914 BRACKET, L.H.
3 1-9190 WHEEL (2)
4 1-5272 SPACER
5 9-0859 SCREW, 3/8-24 x 3-3/4” Hex Head Cap, Grade 5 (2)
6 9-0289 NUT, 3/8-24 Hex Lock Center Lock (6)
7 9-0292 SCREW, 3/8-24 x 3/4” Hex Head Cap, Grade 2 (4)
MANUAL No. 06613 LT SERIES (Small Frame)
2
3
4
5
6
5
1
3
6
4
6
5
1
7
6
2
6
5
7
3
4
