27
6-3131 ACCESSORY, 33” CLAMSHELL GRASS CATCHER
ITEM PART NO. DESCRIPTION
-- 6-3131 KIT, 33” Clamshell Grass
Catcher (
Includes items 1 thru 60)
1 1-7316 TUBE, Grass
2 2-8700 DECAL, Read Manual
(Not Shown)
3 1-1870 GRIP
4 1-6314 WASHER, 11/32 Flat (9)
5 3-6422 WASHER, 3/16 Flat (30)
6 5-8615 WELDMENT, Front Cover
Brace
7 7-2873 COVER, Front
8 7-2874 DEFLECTOR (Not Shown)
9 7-2950 GASKET, Chute
10 9-0307 SCREW, #10-24 x 1/2” Self-
Tapping (3)
11 9-0999 SCREW, 1/4-20 x 5/8” Pan
Head Self-Tapping (9)
12 9-1079 NUT, #10-24 Hex Fl. Lock (22)
13 7-2951 END CAP, Tube
14 5-8600 WELDMENT,
Rear Cover Brace
15 7-2872 COVER, Rear
16 7-2876 GRILL, Rear
Cover (Not Shown)
17 7-3145 BOLT, #10-24 x 1-1/2” Oval
Head (13)
18 7-3179 HINGE, Rear Cover
19 9-1265 SCREW, #10-24 x 1-1/2
Machine (5)
20 7-2964 DECAL, Warning (Not Shown)
21 3-1951 LATCH, Chute/Tube
22 3-1952 BASE, Handle
23 3-7745 HANDLE, Tube
24 9-1303 BOLT, 5/16-18 x 1”
Round Head
Short Neck Carriage, Grade 5
25 9-1314 WASHER, 1/4 Internal Tooth
Lock (3)
26 9-1530 BOLT, 1/4-20 x 3/4” Round
Hd. Short Nk. Carriage, Gr. 5
(3)
27 9-1537 NUT, 5/16-18 Wing
28 9-1576 NUT, 1/4-20 Hex (3)
29 9-1593 PIN, 3/8 Self Lock Cotter (2)
30 9-1514 WASHER, 3/8 Flat (8)
ITEM PART NO. DESCRIPTION
31 9-1601 NUT, 5/16-18 Flange Lock (8)
32 9-1811 BOLT, 5/16-18 x 5/8” Hex
Flange Lock (3)
33 3-1954 SUPPORT, Bumper
34 3-3587 BUMPER, Rear
35 7-3272 SPACER, Bumper Bracket
36 9-0509 WASHER, 1/2 Internal Tooth
Lock
37 9-1270 SCREW, 5/16-18 x 1-3/4” Hex
Washer Self-Tapping (5)
38 9-0646 BOLT, 1/2-13 x 1” Hex Head
Cap Grade 5
39 9-1316 NUT, 1/2-13 Hex Gr. B
40 9-1299 NUT, 3/8-16 Hex Lock (4)
41 9-1304 SCREW, 3/8-16 x 1” Hex Head
Cap, Grade 5 (2)
42 4-4773 WELDMENT, LT Bumper
43 9-0624 BOLT, #10-24 x 3/4” Hex
Flange Lock, Grade 5
44 5-8641* ASSEMBLY, Chute
45 9-1296 WASHER, 5/16” Flat (2)
46 9-1298 NUT, 5/16-18 Hex Nyloc (2)
47 7-3172 LINK, Handle (Right Hand)
48 7-3173 LINK, Handle (Left Hand)
49 7-3171 PLATE, Hitch
50 9-1300 WASHER, 7/16” Flat (4)
51 9-1891 BOLT, 3/8-16 x 1” Hex Flange
Lock (2)
-- 6-0480 KIT, Air Lift (Incl. Items 52-55)
52 3-7723 Air Lift (2)
53 9-0223 NUT, 5/16-24 Hex (6)
54 9-0228 SCREW, 5/16-24 x 5/8” Oval
Head Machine (6)
55 9-0391 WASHER, 5/16 Internal
Tooth Lock (6)
56 9-1905 BOLT, 5/16-18 x 7/8” Hex
Flange Lock (2)
57 7-3262 BRACKET, Bumper Support
(Right Hand)
58 7-3263 BRACKET, Bumper Support
(Left Hand)
59 5-8745 BRACE, Bumper
60 7-3509 SCREEN, Clamshell (not
shown)
*NOTE: 5-8641 includes a bag adapter (part no. 1-9912) and two decals (part nos. 4-6720 & 2-9784).
LT SERIES (Small Frame) MANUAL No. 06613
