43
6-0947 ACCESSORY, BAG-N-WAGON
(Hitch and Body Section)
ITEM PART NO. DESCRIPTION
1 5-1935 ASSEMBLY, Hitch (Includes items 17 thru 30 & 40 thru 44)
2 4-0446 BODY, Wagon Cart
3 3-9604 SUPPORT, Axle
4 3-1949 AXLE
5 5-2667 ASSEMBLY, Wheel/Tire, Pneumatic (Includes indented
items below) (may also use 5-1449 or 5-2305) (2)
-- 1-0820 TIRE, 4.10/3.50x4
-- 1-0819 RIM (Includes indented items below)
-- 1-1807 BEARING, Ball (2)
-- 1-4247 FITTING, Lube
-- 1-0821 TUBE, Inner
6 3-1946 TONGUE
7 1-2391 GRIP, Latch
8 3-7736 LATCH
9 1-3694 SPRING, Latch
10 3-7737 YOKE
11 1-1032 WASHER, Felt (2)
12 1-0935 WASHER, 3/4” (6)
13 9-0364 PIN, 5/32 x 1” Cotter (2)
14 1-1022 COVER, Dust (2)
15 1-1713 PIN, 3/8 x 2-1/4” Clevis
16 1-1714 HAIRPIN, 3/32”
17 1-2388* BALL, Hitch
18 2-1762* COLLAR, Hitch
19 2-9562* BAR, Upper Draw
20 3-7742* BRACE, Draw Bar
21 3-7743* BAR, Lower Draw
22 9-0160* SCREW, 3/8-24 x 1” Hex Head Cap, Grade 5
23 9-0118* WASHER, 3/8” Split Lock
24 9-0155* NUT, 3/8-24 Hex, Grade 2
25 9-0247* WASHER, 7/16” Split Lock
26 9-0460* NUT, 7/16-20 Hex, Grade B
27 1-2389* PIN, Hitch Clevis
28 9-0268* SCREW, 1/2-20 x 1” Hex Head Cap, Grade 2
29 9-0819* NUT, 1/2-20 Hex Jam Lock
30 1-5067* HAIRPIN, 3/32 x 1-19/32”
31 1-2485 RETAINER, 1/4” Bolt (6)
32 9-0053 WASHER, 1/4” Internal Tooth Lock (8)
33 9-0063 NUT, 1/4-20 Hex (8)
34 1-1078 BOLT, 5/16-18 Shoulder
35 1-1079 WASHER, Spring
36 9-0187 WASHER, 5/16” Split Lock
37 9-0196 NUT, 5/16-18 Hex
38 3-1038 DUST-CAP (2)
39 9-0074 BOLT, 1/4-20 x 3/4” Short Neck Carriage, Grade 5 (6)
40 2-7713 CLIP, Retaining
41 9-0206 SCREW, 5/16-18 x 3/4” Hex Head Cap, Grade 2
42 9-0203 SCREW, 5/16-18 x 1/2” Hex Head Cap, Grade 2
43 9-0391 WASHER, 5/16” Internal Tooth Lock
44 9-0184 NUT, 5/16-18 Hex Center Lock
45 1-6648 DECAL, Snapper (1-8593 may be used) (2)
46 1-2464 DECAL, Maximum Load
See Pages 38 and 39 for Dump Wagon Kit.
LT (Small Frame) ACCESSORIES MANUAL No. 06613
HARDWARE BAG #6-
0447 is comprised of
items 11, 12, 13, 14, 15, 16, 31 and 38
shown on this page.
*KIT #6-0734 (Hitch Assembly)
is comprised of these items.
