66
OTHER ACCESSORY KITS
KIT No. DESCRIPTION _
3-2392 TOOL, Smooth Clutch
-used to replace rubber disc without bending it’s hub which causes vibration
6-0327 KIT, Wheel Hub Puller
-to pull LTD wheel hubs
6-0694 KIT, Yoke Spring Attachment
-to increase life of the driven disc
6-1000 KIT, Reverse Assist (for LT12D Series)
-to replace Shift Link Spring for greater shifting control
6-1025 KIT, Brake Cable Extension (for LT12D Series)
6-1163 KIT, Cold Starting (for Hydro Drive Series)
-to provide easier starting in cold weather by disengaging the traction drive belt
6-0691 KIT, Chute Brace (for Snow Thrower Attachment)
6-1289 KIT, 30” Cutting Deck Replacement (for Gear Drive models)
-Includes Deck, Spindle, Belt and Blade
6-1288 KIT, 33” Cutting Deck Replacement (for Gear Drive models)
-Includes Deck, Spindle, Belt and Blade
6-1290 KIT, 38” Cutting Deck Replacement (for Gear Drive models)
-Includes Deck, Spindles, Belt and Blades
6-1314 KIT, 38” Ground Following Cutting Deck Replacement (Hydro Drive models)
-Includes Deck, Spindles, Belt, Blades and Roller
6-1299 KIT, 38” Ground Following Cutting Deck Replacement (for Gear Drive models)
-Includes Deck, Spindles, Belt, Blades and Roller
6-1283 KIT, 42” Cutting Deck Replacement (for Gear Drive models)
-Includes Deck, Spindles, Belt and Blades
6-1266 KIT, 48” Cutting Deck Replacement (for Hydro Drive models)
-Includes Deck, Spindles, Belts and Blades
6-1355 KIT, LTD Pivot Arm Replacement
-limits yoke rotation into rubber disc and binding on chain case pin
6-1787 KIT, Drive Disc Alignment Gauge
-to check for misalignment of driven disc, which can cause early cracking and
chunking of rubber driven disc
MANUAL No. 06613 LT SERIES (Small Frame)
