33” CUTTING DECK, BELTS, BRAKES
ITEM PART NO. DESCRIPTION
1A 5-3690* ASSEMBLY, Deck 33” Cutting
(Includes items 46A & 81)
1B 5-3693** ASSEMBLY Deck, 33” Cutting
(Includes items 46B & 81)
2 2-6558 PULLEY, Spindle, 7” O.D.
3 1-0027 NUT, 3/4-16 Hex Jam
4 1-4304 PIN, 1/4 x 1-1/4” Clevis
5 5-2886 ASSEMBLY, Brake Band
6 3-2169 DRUM, Brake
7 2-4192 ROD, Link, Clutch/Brake
8 1-0740 RING, Retaining (2)
9 3-8018 BRACE, Spindle
10 9-0368 SCREW, 5/16-18 x 3/4” Self-Tapping
11 9-1585 NUT, 3/8-16 Hex Center Lock, Gr. 5
12 1-2264 SPRING, Clutch & Brake
13 4-1487 GUIDE, Belt
14 9-0037 COTTER-PIN, 3/32 x 3/4” (2)
15 9-0055 WASHER, 1/4“ I.D. x 5/8” O.D. Flat
16 2-7717 PULLEY, Idler, 4” O.D.
17 9-0122 WASHER, 3/8 Flat (3)
18 9-1553 SCREW, 3/8-16 x 1-3/4” Cap
19 2-9694 SWIVEL, Brake
20 1-2431 PIN, 1/4 x 1-1/8” Hair (2)
21 2-6677 BOLT, 1/4-20 Eye
22 1-4303 NUT, 1/4-20 Tee
23 9-0063 NUT, 1/4-20 Hex, Grade 5
24 2-6639 ROD, Front Lift
25 3-3938 BRACKET, Front Lift Hanger
26 1-3460 PIN, 3/8 x 1-1/2” Clevis
27 2-7471 PIN, Front Deck Hanger
28 9-1596 HAIRPIN, 5/8” (2)
29 4-1613 LIFT, Front Arm
30 3-2028 WASHER, 3/4“ I.D. Flat (4)
31 1-5272 SPACER (3)
32 1-9190 WHEEL, Gage (3)
33 9-1600 NUT, 3/8-24 Hex Center. Lock, Gr. 5 (3)
34 9-0004 BOLT, 5/16-18 x 1/2” Carriage Gr. 5 (6)
35 9-0585 NUT, 5/16-18 Hex Lock, Gr. 5 (9)
36 9-1532 SCREW, 3/8-24 x 3-3/4” Cap, Gr. 5 (3)
-- 5-2555 ASSEMBLY, Deflector
(Includes items 37, 38, 40, 41, 42, 96)
37 2-6483 PALNUT, 1/4 Hex
38 2-6234 PIN, Hinge
39 9-0612 BOLT, 3/8-16 x 3/4” Flange Lock, Gr. 5 (15)
40 3-3780 HINGE, Deflector
41 2-6233 DEFLECTOR, Discharge
42 2-6831 DECAL, Danger (Cut Finger)
43 2-6546 BELT, Drive, 33” Cutting Deck
44 9-1508 BOLT, 5/16-18 x 3/4” Carriage Gr. 5
45 9-0613 NUT, 3/8-16 Hex Flange Lock (18)
46A 1-4852* DECAL - CAUTION, Deflector
46B 2-2841** DECAL - CAUTION, Deflector
47 9-1296 WASHER, 5/16 Flat (2)
48 9-0492* NUT, 5/16-18 Wing
-- 9-1511** NUT, 5/16-18 Hex, Grade 5
49 9-0130 NUT, 3/8-16 Hex, Grade 5 (2)
50 9-0118 WASHER, 3/8 Split Lock (2)
ITEM PART NO. DESCRIPTION
51 9-0584 BOLT, 1/4-20 x 1/2” Flange Lock. Gr. 5
52 9-0850 BOLT, 3/8-16 x 3/4” Carriage, Gr. 5
53 3-2432 LINK, Adjustment
54 1-5012 ECCENTRIC, Leveling
55 9-0563 SCREW, 3/8-16 X 1” Hex Cap, Gr. 5
56 9-0721 BOLT, 5/16-18 x 1/2” Flange Lock, Gr. 5 (4)
57 3-8453 RAIL, Side (2)
58 3-3952 ANCHOR, Brake
59 5-2917 ASS’Y, Spindle (Incl. 60 thru 70)
60 2-4687 SPINDLE (7.54” Long)
61 1-0817 FITTING, Lube
62 5-2294 HOUSING, Spindle (Incl. item 61)
63 1-2491 RING, Retaining (2)
64 1-3313 BEARING, Spindle (2)
65 1-4407 WASHER, Spindle (2)
66 3-7751 HOLDER, Blade
67 9-1939 NUT, 1/2-20 Hex Jam (4)
68 9-0509 WASHER, 1/2 Int. Tooth Lock (2)
69 9-0491 SCREW, 1/2-20 x 1-1/4" Cap Gr. 5 (4)
70 9-0356 NUT, 5/8-18 Hex Lock, Gr. B or 5
71 5-7482 ASS’Y, Blade/Air Lift (Incl. 72 thru 76)
72 1-9523 BLADE, 33” Cutting Deck Euro
73 3-7723* AIR-LIFT (2)
-- 3-4468** AIR-LIFT (2)
74 9-0228 SCREW, 5/16-24 x 11/16” Machine (6)
75 9-0391 WASHER, 5/16 Int. Tooth Lock (6)
76 9-0223 NUT, 5/16-24 Hex, Grade 5 (6)
77 3-3571 BRACKET, Gage Wheel (Rear) (2)
78 4-2608 BRACKET, Rear Deck Lift, Left Side
79 4-2578 BRACKET, Rear Deck Lift, Right Side
80 2-2991 DECAL, 33” Hi-Vac
81 1-6973 DECAL - CAUTION (Rotating Blades)
82 2-4183 ARM, Pivot
83 3-3578 BRACKET, Pivot Arm
84 3-3926 GUIDE, Belt
85 9-0361 SCREW, 5/16-18 x 5/8” Self-Tap. (2)
86 1-5761 SCREW, 5/16-18 x 3/4” Shoulder
87 9-0583 NUT, 1/4-20 Hex Flange Lock, Gr. 5
88 1-2670 RING, Tolerance
89 3-3586 BRACKET, Link, Clutch/Brake
90 3-3570 BRACKET, Gage Wheel (Front)
91 4-1311 ARM, Idler
92 9-1514 WASHER, 13/32” I.D. Flat (2)
93 9-1503 HAIRPIN, 3/8” (2)
94 9-1587 WASHER, 1/2“ I.D. Flat (2)
95 9-1588 BOLT, 3/8-16 x 3/4” Flange Lock, Gr. 5 (3)
96 1-6341 SPRING, Hinge
97 3-4168 BLADE, 33” Cutting Deck (not shown)
98 2-9152 CABLE, 33 Blade Hydro (not shown,
Attaches to Item 82)
MANUAL No. 06448
NOTES:
5-9063 is a complete 33” domestic deck.
