38” CUTTING DECK ASSEMBLY
(page 4 of 4)
ITEM PART NO. DESCRIPTION
1 1-3847 RETAINER, 3/8” Bolt
2 1-8574 IDLER, 4-1/8” Flat
3 2-4604 BOLT, 3/4” Dia. X 3.01 Shoulder; 1/2-13 Thread
4 2-4607 SWIVEL, Brake Link
5 2-6122 WHEEL, Gage 38” Deck (3)
6 2-6831 DECAL, CPSC Cut Finger
7 2-7168 SCREW, 5/16-18 x 1” Hex Head Cap, Grade 5 (3)
8 2-9425 CHUTE, Discharge 38” Deck
9 2-9617 WASHER, 3/4” I.D. Flat
10 3-5500 BELT, 38” Deck Dual Spindle Brake
11 3-5502 ROD, Pivot, Side Discharge
12 3-5503 ROD, Mounting, Side Discharge
13 3-5507 PIVOT, Dual Brake (2)
14 3-5510 BRAKE LINK, Dual Spindle Brake (2)
15 3-5518 LEVER, Engagement
16 3-5529 GUARD, Belt, 38” Dual Spindle Brake
17 3-6586 J-BOLT, 3/8-16 x 6-1/4”
18 4-2595 ARM, Brake (2)
19 5-4096 ASSEMBLY, 38” Dual Brake Deck
20 4-2596 ARM, Idler, Dual Brake
21 3-5496 BEARING, 3/4” I.D. (2)
22 9-0289 NUT, 3/8-24 Hex Center Lock, Grade 5 (3)
23 9-0553 SCREW, 5/16-18 x 3” Hex Head Cap, Grade. 5 (2)
24 9-0975 NUT, 1/2-13 Hex Center Lock
25 9-1158 BOLT, 3/8-16 x 1-3/4” Short Neck Carriage, Grade 5
26 9-1294 WASHER, 1/4” I.D. Flat (4)
27 9-1302 NUT, 3/8-16 Hex, Grade 5
28 9-1331 WASHER, 13/32” I.D. Flat
29 9-1508 BOLT, 5/16-18 x 3/4” Short Neck Carriage, Grade 5
30 9-1514 WASHER, 13/32” I.D. Flat Lock (3)
31 9-1526 BOLT, 5/8” Dia. Shoulder, 3/8-24 Thread (3)
32 9-1541 SCREW, 5/16-18 x 3/4” Self-Tapping (2)
33 9-1575 NUT, 5/16-18 Hex Center Lock, Grade 5 (3)
34 9-1587 WASHER, 1/2” I.D. Flat (3)
35 9-1310 PIN, #13 Hair (2)
36 9-1597 PIN, 3/32 x 3/4” Cotter (4)
37 9-1601 NUT, 5/16-18 Hex, Grade 5 (4)
38 9-1675 WASHER, 11/32” I.D. Flat (4)
39 9-1775 WASHER, 1/2” I.D. x 2-1/2” O.D. Special “D”
40 9-0613 NUT, 3/8-16 Hex Flange Lock
41 1-2264 SPRING
42 2-9025 SPRING, Extension
43 9-0971 SCREW, 1/4-20 x 2-3/4” Hex Head Cap, Grade 5
44 9-0063 NUT, 1/4-20 Hex, Grade 5
45 9-0477 NUT, 1/4-20 Hex Flange Lock, Grade 5
46 9-1596 HAIRPIN (for 5/8” diameter shaft)
47 2-7471 PIN, Deck Hanger
48 3-5813 SPRING, Side Discharge
49 2-6154 DECAL, 38 Inch Deck
MANUAL No. 06448
NOTES: 5-8404 is a complete 38” dual brake cutter deck assembly.
