10
Features & Controls
Throttle Control
The throttle controls engine speed. Move the throttle
forward to increase engine speed and back to decrease
engine speed. Always operate at FULL throttle.
Choke
Close the choke for cold starting. Open the choke once
the engine starts. A warm engine may not require
choking. Move the lever forward to close the choke.
Headlights
The light switch turns the tractor headlights on and off.
Hour Meter (Select Models)
The hour meter measures the number of hours the key
has been in the RUN position.
Control Functions
The information below briefly describes the function of individual controls. Starting, stopping, driving, and mowing
require the combined use of several controls applied in specific sequences. To learn what combination and sequence
of controls to use for various tasks see the OPERATION section.
Figure 1. Controls
