Features and Controls
A - Throttle Control / Choke Control Levers — Throttle
control increases or decreases the speed of the engine.
Choke control engages the choke to start a cold engine.
B - Steering Wheel (Removed for clarity) — Steers the unit.
C - Brake Pedal — Quickly stops the unit.
D - Deck Lift Lever — Changes the height of cut.
E - PTO Switch — Starts and stops the rotation of the
blades.
F - Cruise Control — Locks ground speed in forward.
G - Reverse Mowing Option (RMO) — Allows engaging of
mowing deck while traveling in reverse.
H - Ignition Switch — Starts and stops the engine. (Note:
The headlight switch is incorporated into the ignition switch.)
I - Parking Brake Lever — Engages the brake when you leave
the unit.
J - Speed Control Pedal — Changes the speed and the
direction of the unit.
K - Automatic Drive Disconnect (not shown, located under
the seat) — Disengages the transmission.
13
English
