Assembly
Read and follow the assembly and adjustment
instructions for your mower.
All fasteners are in the parts bag. Do not discard any
parts or material until the unit
is assembled.
NOTE: In this instruction book, left and right describe the
location of a part with the operator on the seat.
WARNING: Before doing any assembly or
maintenance to the mower, remove the wire from the
spark plug.
8 www.snapper.com
Parts Bag - Contents
The fasteners and other loose parts are shown below. The fasteners
are shown full size. The quantity is shown in brackets ( ).
Figure 3: Parts bag components
A - (2) Carriage bolt
B - (2) Hex nut
C - (1) Bolt
D - (1) Washer
E - (2) Knob
F - (2) Washer
G - (1) Keys & ring
H - (1) Terminal cover
A
B
C
D
E
G
H
F
