32
Troubleshooting, Adjustments, & Service
FUSE REPLACEMENT
1. Park the rider on a smooth, level surface such as a
concrete floor. Disengage the PTO, lock the motion
control levers into their neutral locked positions, turn
off the engine, and remove the ignition key.
2. Raise the seat. The fuse holders are located on the
right side of the rear seat support. See Figure 36.
3. Remove and check the suspected fuse (or fuses). If
blown, replace with a fuse with a rating equal to the
ratings indicated in Figure 36.
WARNING
Do not use a fuse with a rating other than that
specified. Serious equipment damage may result.
A
Figure 36. Fuse Designations and Ratings
A. Accessory - 30 Amp
B. Start - 15 Amp
B
